Bandoneon Notation

written by Ricardo Fiorio
translation of the original by Sheldon Sper

April 2005

The following examples show some characteristic sounds and techniques of the bandoneon and are meant to serve as a help to those composers and arrangers who desire to write for this versatile instrument, which, unfortunately, has little original literature, perhaps because of the little knowledge that exists concerning its immense musical richness.

Example 1

Figure: A fragment of the variación of RESPONSO by Aníbal Troilo
Image Responso

The presentation of the theme in a rhythmic figuration, generally in sixteenth notes, which appears in the final section of many instrumental tangos is called variación. The present example is a fragment of the variación. of the tango RESPONSO by Aníbal Troilo (figure 1).

In the example one can hear the timbre of the right keyboard of the bandoneon almost in its entire register since the variación. reaches to the upper limit of the right hand opening and a fourth above the lowest limit.

The recording of this example was made incorporating an effect of reverb, because the dry sound, especially in the very high tones does not come off as natural.

Example 2

Figure: Bandoneón, from the SUITE TROILEANA by Astor Piazolla
Image ejemplo2

The SUITE TROILEANA of Astor Piazolla (figure 2) begins with a free cadenza (written without bar lines in the original) for left hand alone.

Besides the particular sound characteristic of the left keyboard of the bandoneon, in this example one can appreciate two interesting properties of the instrument: on one hand the capacity to produce chords consisting of widely separated notes. The last chord, for example, is composed of three notes in the upper limit of the high register sounding simultaneously with a note almost in the lower limit of the left hand. On the other hand, one can also note the vibrato effect which is achieved by vibrating the bellows of the instrument.

(acoustic example)

Example 3

A fragment of an invention for three voices of J. S. Bach has been used for this example (figure 3). The goal is to demonstrate the possibility that the bandoneon has of using distinct timbres and types of key strokes (touches) simultaneously. To this end the example is divided in five partes and the score is written on three staves, each one corresponding to a voice. (acoustic example)
  1. In the first part one hears the left hand in the middle and low registers corresponding to the keyboard. The touch is detached, a key stroke between legato and non legato. The sound is brilliant and a bit metallic. It corresponds to the first staff of the score.

  2. In the second part one hears the left hand in its medium high register, with a very velvety sound, and the touch is (note that the bandoneon, like an organ or an accordion, can unite continuous sounds, something that a piano for example, cannot do.) It corresponds to the second staff of the score.

  3. The third part corresponds to the third voice of the score. This part placed in the medium low register of the left hand keyboard with a non legato touch similar to the one used by bowed instruments. The sonority is similar to that of a cello playing in basso continuo

  4. Two low voices playing simultaneously by the left hand are shown in the fourth part. To be able to maintain the upper voice legato one should take advantage, at various places, of changing the finger already pressed on a key, in accordance with the indications in the score, in order to free up fingers destined for the other voice. This resource (technique) is also used very frequently in playing the organ. Even if the recording is made in this manner to exemplify the aforesaid, en the score is added another fingering possibility, beginning with the bellows closing instead of opening, which makes the execution notably easier. One of the big advantages which bisonoric bandoneons have (with different chord voicings depending on whether one is closing or opening the bellows) is the possibility of choosing the fingerings most comfortable to the player.

  5. Finally, in the fifth part one plays the three voices simultaneously.

Figure: Fragment of a three part invention of J. S. Bach
Image Bach

Example 4

Figure: Fragment of OJOS NEGROS by Vincente Greco in an arrangement by Rodolfo Mederos
Image ejemplo4

This example (figure 4) is a fragment of an excellent arrangement for unaccompanied bandoneon made by Rodolfo Medeos on the tango OJOS NEGROS by Vincente Greco.

The example is divided in three parts. (acoustic example)

  1. In the first voice one hears the left hand, which begins in the low register of the keyboard, with a legato touch. In bars 5,6, and 7 a rhythmic base is generated from the point where the wide chords are pushed frin the end of the previous bar. The arrastre or push is a bandoneonistic device used frequently in tango which consists of attacking the chords approximately an eight note before the beginning of the measure, accenting the chords by means of the bellows in the beginning beat of the measure and finishing the rhythm with a softer repetition on the second eighth note of the first beat. In the way, a syncopated rhythm is produced, very characteristic of the tango, which generally is concluded with a quarter note on the third beat.

    In bars 9, 10, and 11 are shown open (widely distributed) chords but with a legato touch, which contour a sustained harmony very full, despite being comprised of only three notes.

    In bars 13, 14 and 15 a percussive effect is produced using harmonic intervals of seconds alternating in syncopation between the medium and low registers of the left hand.

  2. The second part of the example shows the expressive possibilities of the right hand by means of the utilization of different touches. One uses different gradations of air on legato notes in order to give expression to the phrase (a possibility also in that vocal music or string instruments also exhibits) and different types of accents, stacattos, two note slurs, and ornamental appoggiaturas.

  3. The third part of the example is a combination of bath hands.

Note: As you would be able to appreciate in the examples of tango, the notation does not correspond exactly with the execution. This occurs because one of the key elements in the interpretation of tango is what is called phrasing, which is a particular way of speaking the melodies, perhaps linked possibly to the inflections of daily speech. It is a very wide theme which merits a separate detailed study.

Example 5

The first impression that the keyboards of the bandoneon create is that of disorder. With other instruments the notes are arranged in an evidently logical sense (for example, the sequence of content and black keys on the piano is absolutely transparent). With the bandoneon this order is mysterious. The notes seem not to be where one would expect them to be. To top it all off, in bisonoric bandoneons, a single key can produce different notes depending upon whether on is opening or closing the bellows. Nor is there an evident logic in this, since the sound can vary by a tone, a semitone, a fifth or not vary at all, depending on the key in question. To complete the travails of the aspiring bandoneonist, the keyboards stay out of the view of the player, (something that has caused severe neck pains to more than one person in trying to observe the fingers on the keyboard). Even if the keyboards could be seen easily, one would only see a succession of rows of keys monotonously the same, with the sole difference of some numbers - also mysterious - near the buttons, numbers worn away by time in the majority of instruments actually in use.


Such complexity- aside from discouraging a number of students - has given rise to opinions of all kinds. It is quite common to hear, (even from the lips of oustanding bandoneonists !) that the arrangement of the keyboard of the bandoneon is the work of some crazy. Nothing is further from the truth. The keys of the bandoneon allow all the notes to be within the reach of the hand of the instrumentalist, a fact that makes it possible to play in all of the major or minor0 keys more or less with the same degree of difficulty. Actually, except for the question of familiarity, playing a C major scale presents the same degree of difficulty as executing a scale in Dmajor ♭. And almost just as surely anything that can not be done with the opening keyboard can be done with the closing one.


This proximity of the notes permits, aside from the distribution of very open chords that we have already studied, the possibility of playing melodies with very widely spread intervals at a good speed, something that would be impossible on other instruments. As proof of this, try playing the third measure of (example 5) on the piano. Can it be done?


Certainly taking up the bandoneon initially is not simple. Instruments like piano or guitar allow a more rapid initial gratification. But we should consider that, with the objective of constructing an instrument that could be played in all keys, that would have touches like a guitar, that could join sounds continuously like an organ, that would have a range (register) equal to that of a harpsichord, would have the possibility of varying intensities of sustained sounds like a violin, that would have different distinct attacks like brass instruments and that would have a sonorous volume similar to that of a piano - among other things - and above all that would be portable and easily transportable, what the designers and builders of the bandoneon have accomplished is almost miraculous and amply justifies the effort which the study of the instrument entails.


Example 5 is a fragment of the tango EL MARNE, by Eduardo Arolas sound excerpt

(... theses tangos of Arolas and of Greco that I have seen danced on the sidewalk said Borges in his peom El Tango), arranged as a bandoneon solo by Leoploldo Federico and Felix Lipesker. In my opinion it is is one of the best solos for bandoeon that has ever been written. The resources of the bandoneon are taken advantage of to the maximum, above all in the bandoneon's use as a tango instrument. The sound quality is attacked, an effect which is only possible using the opening bellows, which takes advantage of the weight of the instrument for producing accents and syncopes characteristic of the style. For the same reason, it is necessary to create some breaths (closing the bellows rapidly by means of the escape valve in order to return to the bellows-opening attack) like the one you hear clearly in measure 7, breaths that are, without exaggeration, part of the style.


According to the publishing house Julio Korn, the original is written in 4/8 time. I thought that writing it in 4/4 would make more easily readable without changing its interpretation.

Figure: Excerpt of the tango EL MARNE by Eduardo Arolas,
arranged for bandoneón solo by Federico-Lipesker
Image ejemplo5

Suggestions

This page has been created due to questions presented by composers willing to write for the bandoneon. Prof. Ricardo Fiorio has expressed his disposition to contiue this collection of examples as those interested express their doubts. Therefore it is required to colaborate each one by expressing the questions directly to by e-mail.
